JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3－101
3
Procedures
1) Open the Brilliance Setting menu by performing the menu
operation below.
→
→
Display Brilliance Setting menu will appear.
Setting brilliance of each element
• Specify the brilliance for the element.
•
Level4 indicates maximum brilliance and Level1 indicates minimum brilliance.
• The brilliance for the following elements can be specified.
3.8.5.4 Setting radar video brilliance (VID)
The brilliance of the video on the radar display is adjusted.
Procedures
1) Left-click the button located at the lower right of the
radar display, and adjust the brilliance of the radar video so as to
get the best view of the video display.
The brilliance of the radar video can be adjusted on four stages without opening the
Brilliance Setting menu.
Adjust the radar display to obtain the best-to-view video.
: The brilliance of the radar video is selected.
: The brilliance of the radar trails is selected.
: The brilliance of the target symbol is selected.
i
i. Minimum level is Level0.(it means OFF)
: The brilliance of the range rings is selected.
: The brilliance of the EBL / VRM / PI is selected.
: The brilliance of the character and bearing scale is
selected.
: The brilliance of the own ship symbol, heading line, and
own ship vector is selected.
: The brilliance of the operation panel is selected.
i
i
Those selected brilliance can be saved for each Day/Night mode.
Main
7. Sub Menu
2. Brilliance Setting
RADAR Video
RADAR Trails
Target Symbol
Range Rings
EBL/VRM/PI
Character
Own Symbol /HL/Vector
Keyboard
VID
○
To Next Page
