7ļ¼26
JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.2 SETTINGS
7.2.10 Network Setting (Network)
The system can receive data from other system via the JRC LAN. The purpose of
JRC-LAN is interoperation with other JRC systems. The JRC systems are
synchronized with datum in JRC-LAN network.
ā¢
Accepted Devices
ā¢
Receivable Data
[1] Route Data
The system can display the route created by other JRC navigation equipements. Refer to
Section 3.7 "USE ROUTE FUNCTION".
[2] Sensor Data
The system can receive sensor data (Heading, Speed etc...) from other system (ECDIS,
Chart RADAR etc...).
[3] AIS Data
The system can receive AIS data from AIS.
[4] Selected GPS number
Selected GPS number can be synchronized.
[5] Day/Night mode, operation panel brilliance.
Day/Night mode and operation panel brilliance can be synchronized.
i
To connect JRC-LAN, LAN cable and HUB (option) is
necessary. For details, contact the JRC offices.
NOTE: If the connection is not suggested from JRC office, don't connect PC or other
maker's system to JRC-LAN.
ā¢Connecting PC or other maker's system may cause a lower radar system performance.
ā¢Connecting PC or other maker's system may cause a lower that performance.
RADAR : JMA-7100/9100/5300MK2 Series
ECDIS : JMA-901B/701B
Chart RADAR : JMA-900B Series
Conning Display : JMA-901B-CON/701B-CON
Route planning system : JAN-1186
Navigation workstation : NDC-1186
GPS/DGPS : JLR-7500/7800
i
When the system display Route which are created in the ECDIS,
following items are not displayed.
ā¢ XTL
ā¢ Arrival Radius
ā¢ ROT
ā¢ Turn Radius
ā¢ Time Zone
ā¢ Sail
To Next Page
