JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.9 USE FUNCTION KEY [USER]
3ļ¼115
3
page 2-[1]~[7] PL (Pulse Length)
ā¢ Sets the standard transmitter pulse length in each range.
ā¢ When the range is called, the pulse range is used.
page 3-[1]~[7] Video setting menu (Process Setting)
ā¢ Operation is the same as that of the Process Setting menu described in Section
3.8.1 "Set Radar Signal Processing (Process Setting)".
page 4-[1]~[7] Radar trails settings (Trails Setting)
ā¢ Same functions as in the Trails Setting of the RADAR Menu described in
Section 3.8.2 "Set Radar Trails (RADAR Trails Setting)".
page 5-[1] Gain Offset
ā¢ Corrects gain while the function mode is called.
ā¢ Since the displayed noise level varies depending on the combination of the
video process mode and the interference rejection level, gain needs fine
adjustment for always obtaining the highest level.
ā¢ The gain correction function saves the correction value set by the gain adjust in
each function mode, so it can obtain the highest gain without the gain adjust
being operated when the function mode is changed.
ā¢ To set high gain, set a value on the ā+ā side.
ā¢ To set low gain, set a value on the ā-ā side.
ā¢ When the radar interference rejection level is increased, the noise level is
lowered. Thus, set a gain correction value to the ā+ā side.
ā¢ When the video process mode , , or
is used, the noise level is lowered. Thus, set a gain correction
value to the ā+ā side.
ā¢ When the video process mode or is used,
noise is hard to disappear. Thus, set a gain correction value to the ā-ā side.
page 5-[2] PRF
ā¢ Same function as in the TXRX Setting described in Section 3.8.3 "Set Scanner
Unit (TXRX Setting)".
3Scan CORREL
4Scan CORREL
5Scan CORREL
Remain Peak Hold
