7.3.3.2 Adjustment of Main Bang Suppression Area (MBS Area)
Procedures
1) Open the Serviceman Menu.
2) Perform the following menu open procedure to open the MBS
Area adjustment menu.
ā
ā
3) Set the radar as follows:
ā¢ Set the radar range to 0.125 NM.
ā¢ Set the radar video enhance function (ENH) to OFF.
ā¢ Set the image processing (PROC) to OFF.
ā¢ Turn the [RAIN] control to the minimum position (fully to the left).
ā¢ Turn the [GAIN] control to the maximum position (fully to the right).
ā¢ Turn the [SEA] control to achieve the strength with which main bang can be judged.
4) Adjust the value so that the main bang can be erased.
9. RADAR/TT Initial Setup
3. MBS
2. MBS Area
To Next Page
