JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.9 CONNECTIONS WITH ECDIS
3－35
3
3) Select the communication port through which the sentence to be set is output.
4) Select the output format, talker, and transmission interval.
Signals for which the above items can be set:
*For TTM, TLL, OSD, RSD, and ALR, the talker is always RA .
*For GGA, GLL, RMC, and VTG, the talker is always GP.
Settable sentences
TTM(TT)、TLL(TT)、TTD(TT)、TLB(TT)、OSD、RSD、ALR、ACK、
TTM(AIS)、TLL(AIS)、TTD(AIS)、TLB(AIS)、RemoteMaintenance、
JRC-ARPA、APB、BOD、GGA、GLL、RMC、RMB、VTG、XTE、
BWC、HDT、THS
Selectable ports
MAINTENANCE/LOG、NAV1、NAV2、ALARM、JARPA、ARPA、COM
NMEA0183 Output Format
Signal names: APB, BOD, GGA, GLL, RMC, RMB,VTG, XTE, BWC, HDT
Options:
V1.5 V2.0 V2.3
NMEA0183 Talker
Signal names: APB, BOD,RMB, XTE, BWC, HDT
Options: STANDARD: The talker is RA.
GP: The talker is GP.
NMEA0183 TX Interval
Signal names: APB, BOD, GGA, GLL, RMC, RMB,VTG, XTE, BWC, HDT
Options: Set an interval in the range 1 to 9 seconds.
