JRC JMA-9123-7XA - Antenna Height Setting

4－12
JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.7 ANTENNA HEIGHT SETTING
4.7 ANTENNA HEIGHT SETTING
Set the radar antenna height above sea level, but do not change this setting
casually.
Procedures
1) Measure the height from the sea level to the radar antenna in advance.
2) Open the [Service Man Menu] screen.
3) Open the [1.Antenna Height] screen according to the operation shown
below.
The Antenna Height menu will appear.
4) Select the antenna height measured in procedure 1 from the pull-down menu.
1. Adjust Menu
→
4. TXRX Adjustment
→
1. Antenna Height
