1－2
JMA-9100/7100 Installation Manual > 1.EQUIPMENT COMPOSITION > 1.1 GENERAL COMPOSITION
Ex)NKE-1139-1 D, NKE-1129-92 D, NKE-2254-6HSD,
1.1.2 JMA-7100 SERIES RADAR
１：
AC 100-115V 50/60Hz 1φ
２：
AC 220-240V 50/60Hz 1φ
Ｄ：
HEATER OPTION
Table1-3： JMA-7100 SERIES RADAR LIST OF COMPOSITION (Self-Standing TYPE)
MODEL SCANNER UNIT RADIATOR
PERFORMAN
CEMONITOR
TRANSMITTER
RECEIVER UNIT
DISPLAY
UNIT
AC-DC
CONVERTER
JMA-7133-SA NKE-1139 NJU-84 NTG-3230 NCD-4790
―
JMA-7132-SA NKE-1130
―
JMA-7123-7XA NKE-1129-7 NAX-16B-7 NJU-85 NTG-3225
JMA-7123-9XA NKE-1129-9 NAX-16B-9
JMA-7122-6XA NKE-1125-6 NAX-16B-6
―
JMA-7122-9XA NKE-1125-9 NAX-16B-9
―
JMA-7122-6XAH NKE-2254-6HS NAX-16B-6
― NBA-5135
（DISPLAY UNIT
に内蔵）
JMA-7110-6XA NKE-2103-6 NAX-16B-6
―
JMA-7110-6XAH NKE-2103-6HS NAX-16B-6
―
Table1-4： JMA-7100 SERIES RADAR LIST OF COMPOSITION (Desktop TYPE)
MODEL SCANNER UNIT RADIATOR
PERFORMAN
CEMONITOR
TRANSMITTER
RECEIVER UNIT
DISPLAY UNIT AC-DC
CONVERTER
JMA-7133-SA NKE-1139 NJU-84 NTG-3230 Display unit:
NWZ-170
Radar Process
Unit:
NDC-1399-9
Operation
Unit:
NCE-5163
―
JMA-7132-SA NKE-1130
――
JMA-7123-7XA NKE-1129-7 NAX-16B-7 NJU-85 NTG-3225
―
JMA-7123-9XA NKE-1129-9 NAX-16B-9
―
JMA-7122-6XA NKE-1125-6 NAX-16B-6
――
JMA-7122-9XA NKE-1125-9 NAX-16B-9
――
JMA-7122-6XAH NKE-2254-6HS NAX-16B-6
―
NBA-5135
JMA-7110-6XA NKE-2103-6 NAX-16B-6
―
JMA-7110-6XAH NKE-2103-6HS NAX-16B-6
―
