3－74
JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
2) Left-click the button.
The Waypoint inserting mode is selected.
3) On the radar display, put the cursor on the section line into
which a Waypoint is to be inserted, and left-click.
The section is specified, the cursor becomes a cross cursor mark, and the cross cursor mark is
connected to the previous and following Waypoints by a rubber band.
4) On the radar display, put the cursor on the location at which a
Waypoint is to be inserted, and left-click.
The coordinates of the new Waypoint are specified, and the new Waypoint is connected to
the previous and following Waypoints by a line.
5) To insert another Waypoint, repeat procedures 3 and 4.
6) To finish inserting a Waypoint, left-click the
button.
The Waypoint inserting mode will be cancelled.
(Example)
6. Insert
6. Insert
001
10.0kn
090T
Waypoint is inserted into this section.
001
090T
Waypoint is inserted into this section.
Rubber band
10.0kn
