7－44
JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.4 MAINTENANCE MENU
7.4.5 Update of Character String Data (String Data Update)
The system is designed to transfer and display external character strings as the
second language display. The second language is factory-set to "Japanese."
Ask our agent or sales department for the supply of character strings to be
updated.
To update character strings, the flash memory card (option) containing the
character string file must be inserted in card slot 2.
Procedures
1) Open the Serviceman Menu.
2) Perform the following menu open procedure to open the String
Data Update menu.
→
3) Select in the Confirmation Menu.
The character string file on the flash memory card is read into the system, and the second
language area is updated.
To display the read character strings in the second language, select Other in the menu
shown in Section 7.2.6 "Language Setting (Language)".
3. Maintenance Menu
6. String Data Update
1. Yes

JRC JMA-9123-7XA Specifications

General

Type	X-band radar
Frequency	9410 MHz ± 30 MHz
Output Power	25 kW
Antenna Rotation Speed	24 rpm
Operating Temperature	-15°C to +55°C
Range	96 nautical miles
Display	Color LCD
Antenna Length	7 feet (2.1 meters)
Display Size	12.1 inch
Display Resolution	800 x 600 pixels
Range Scales	0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96 NM
Beam Width	1.2° horizontal
