JRC JMA-9123-7XA User Manual

7－4
JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.1 SETTINGS AT INSTALLATION
Table 7-1： Gyro and Log Select Switches (S1 DIP Switch)
1 2 3 4 5 6 7 8
GYRO SIG
STEP ON
SYNC OFF
360X OFF OFF
180X ON OFF
90X OFF ON
36X ON ON
DIRECTION REV ON
NOR OFF
LOG SIG
TYPE SYNC ON
PULSE OFF
PULSE/
NM
Don't care OFF
100P／30X
ON ON
200P／90X
OFF ON
400P／180X
ON OFF
800P／360X
OFF OFF
Table 7-2： Gyro and Log Select Switches (S2 DIP Switch)
S2 SETTING TABLE 1 2 3 4 5 6 7 8
OTHER SETTING
LOG ALARM ON
OFF
GYRO SIMULATOR ON
OFF
LOG SIMULATOR ON
OFF
N.A.
Don't care
any
GYRO ALARM TIME 5s ON
0.2s OFF
HEADING SENSOR SOURCE NMEA(HDT/THS) ON
GYRO SIGNAL OFF
NMEA BAUDRATE SETTING 4800 OFF OFF
9600 ON OFF
19200 OFF ON
38400 ON ON
