JTS PCP HAND PUMP - Package Contents; Assembly

1. PACKAGE CONTENTS
PUMP HANDLE X1
PUMP CYLINDER ASSEMBLY X1
HOSE ASSEMBLY X1
DEAD HEAD X1
ASSEMBLY WRENCH X1
PRESSURE GUAGE X1
CHECK VALVE TOOL X1
SPARE 22MM O’RING X1
SPARE 20MM O’RING X1
SPARE 25MM O’RING X1
BALL INFLATOR ADAPTER X1
3MM ALLEN WRENCH X1
SPARE 5MM O’RING X3
SPARE 7MM O’RING X3
SPARE CHECK BALL SPRING X1
SPARE CHECK BALL X1
2. ASSEMBLY
STEP 1: Align pump handle
with top of cylinder assembly as
shown and rotate clockwise until
it is rmly attached to cylinder.
Tighten with assembly wrench
STEP 2: Remove dust/moisture
caps
