25
MINIATURE MUSIC INSTRUMENT WIRELESS SYSTEM
Binding
When relevant parameters are set, press the key to transmit the
digital binding data to the transmitter by using the ultrasonic transmitter,
while setting relevant parameters synchronously. When data is being
transmitted, the indicator ashes quickly. When the synchronization is
completed, the receiver receives the corresponding channel or frequency,
and the light will stop immediately. If no signal is received after a period of
time, the light will ash slowly, informing the user of the failure of binding
(the slow ash can be cancelled by pressing any key).
Note: The optimum binding distance is 10~60cm, ±30°.
-30 +30
10~60cm
Note 2: Only one transmitter can be synchronized at the same time. When RX1 is
synchronized, RX2 cannot use the synchronization function until the completion of
synchronization of RX1.
SET
To Next Page
