26
Push and hold the “SET” button
to enter the setting mode.
◎ Group / channel setting
Select the group when “G” is ashing; select the
channel when “CH” is ashing.
G: group Select default group 1~6
CH : channel Select default channel, 1~22
max
◎ Channel scan
SC oF This means the function is deactivated.
SC on This means the function is activated.
(scan to make sure this channel is oc-
cupied or not)The program will avoid
it automatically to prevent interfer-
ence.
Parameter setting
This function is deactivated.
◎ Audio output attenuation (XLR)
At oF No attenuation at audio output
At on 20dB attenuation at audio ouput
-5~+10dB;
select SQ
with ▲/▼
-5 is the maximum sensitivity.
+10 is the minimum sensitivity.
The default setting is 0.
This function is deactivated.
◎ SQ receiving sensitivity
The default setting is 0.
6-1-2 How to use //
