JTS RU-8012DB - Page 12

08
Front panel Rear panel
19 20 21 221
3
25
7
4
8
6
Female BNC antenna port: the 50Ω BNC antenna is connected here. It
also provides a booster power of 12~15 DC / 100mA for an external
antenna booster.
6.3mm phone jack: unbalanced audio output jack
3P XLR male: balanced audio output jack
DC power socket: for 12~15V DC / 300mA power supply
19
20
21
22
1 8
~ : See page 5.
19
4-1-2 UHF PLL single-channel diversity receiver //
