JTS US-901D - Handheld Transmitter;; Mh-950 Mh-960

16
(1) Turning the transmier on/o
e on/o switch is located on the boom of the microphone.
(2) Inserting and changing the baery
1. Loosen the microphone head counter-clockwise. (Figure 1)
2. Hold on to both baery tray buons to release it. (Figure 2)
3. Insert 2 pieces of UM-3 1. 5 V baeries, remember to match
correct polarity. (step1 of Figure3)
4. Directly push the baery tray back. (step2 of Figure3)
5. Aim the connectors exactly for screwing on the microphone
head clockwise. (Figure 4)
(3) LCDpanel
Main display
Baery indicator
5-2 Handheld Transmitter // Mh-950 Mh-960
2
1
Figure 1
Figure 2
Figure 3
Figure 4
