18
(1) Insert 2 pcs 1.5V baeries into the baery tray.
(2)Aer puing into the baery, switch on the power switch.
Battery Insertion // Mh-920 / Mh-930 / Mh-850 / Mh-750
Battery Insertion // Mh-8800i
(1) Loosen the microphone head counter-clockwise. (Figure 1)
(2) Hold on to both baery tray buons to release it. (Figure 2)
(3) Insert 2 pieces of UM-3 1.5 V baeries, remember to match
correct polarity. (Step 1 of Figure 3)
(4) Directly push the baery tray back. (Step 2 of Figure 3)
(5) Aim the connectors exactly for screwing on the microphone
head clockwise. (Figure 4)
(6) e on/o switch is located on the boom of the microphone
5-2 Handheld Transmitter
Figure 1
Figure 2
2
1
Figure 3
Figure 4
Mh-8800i
Battery tray
Power switch
Mh-8800i
To Next Page
