24
Operation
USING JUGS FOR LACROSSE:
1. Follow the assembly instructions for the “High Profile” setup as shown in
Figure 9 on page 15, or use straight legs.
2. Install the small diameter feed chute for lacrosse (see Figure 11), and
position the rubber pad bracket until the bolt holes line up with the lower set
of bolt holes in the rotating plate (see Figure 12).
3. Follow the general operating instructions as described in steps 1- 6 on
page 17.
The following diagrams depict the proper position of the feed chute for
various shots or passes:
high “lob” Tosses Bouncing Passes “Straight Line” Throws
