26
Transporting
1. Using the vertical T-clamp, lock the rotating plate in “pop fly to catchers”
position (vertically upward).
2. Make sure the horizontal T-clamp engages the indentation of the base shaft.
This is done by lining up the horizontal T-clamp with the red dot on the base
casting, and hand-tightening the T-clamp.
3. Lower JUGS to a horizontal position, with the feed chute facing upward.
4. Slightly loosen the base T-clamp that secures the legs.
5. Grasp two legs, and twist them towards your sides.
6. Tighten the base T-clamp.
7. Grasp and lift the two legs. Roll JUGS as you would a wheelbarrow.
