Operating instructions
⚠ 
· Use your charging equipment exclusively at power sock-
ets and charging staons for which you have original
JUICE mains adapters. The device charges your vehicle
with single- or three-phase AC voltage ranging from 6
to 32 ampere (A). Use only original JUICE accessories
equipped with the original JUICE CONNECTOR.
· Protect your charging equipment against damage from
being run over, dropped, yanked, kinked or crushed.
· To prevent overheang while charging, do not expose
your JUICE BOOSTER 2 to direct sunlight or other
sources of heat for long periods of me. If the JUICE
BOOSTER 2 becomes overheated, charging is automat-
ically interrupted unl the unit’s temperature drops to
within its normal operang range.
· In many countries, industrial power outlets must be
equipped with a Type-A residual current device (RCD).
JUICE recommends that a Type-A RCD be installed in
power sockets of any kind. Please observe the regula-
ons in force in the country of use, as these always take
precedence. As the JUICE BOOSTER 2 is already ed
with a built-in DC residual current monitor, you don’t
have to bother with pricey installaon of a Type-B RCD
or Type-A power supply.
Function display
Buon for charging status/mode SELECT

AMPERE: Displays the automacally set or individually
reduced amperage value (i. e. the charge intensity).

MODE: Indicates the preselected mode.

FAULT: Displays the cause in case of a fault.
On the back of the device you’ll nd a How-To
quick-start guide, hazard warnings, the unit’s serial
number and other product informaon.
Charging instructions
⚠ 
· Always perform charging operaons in the specied
order of steps.
· Always stop the charging process before you remove
the charger vehicle-end connector from the vehicle
charger socket.
· Never disconnect any plug (neither from the power
socket, nor on the JUICE CONNECTOR) while the
charging process is ongoing.
· Potenal charging faults (FAULT) are idened on the
device’s funcon display. (Further informaon in this
regard can be found in the secon on Fault indicaons).
· Vehicles ed with a Type-2 charging socket lock the
charge coupling during the charging process, and the
coupling remains locked as long as the car is locked.
This protects the JUICE BOOSTER 2 against the.
· Should any unauthorised party disconnect the mains-
end cable from the power socket during the charging
process, when the cable is reconnected to the socket
the charging process will automacally connue at the
recently detected or manually reduced charge current
intensity.

Please consult the vehicle user manual for informaon
on plugging in the connector, locking and unlocking the
coupling, stopping the charging process, unplugging the
connector from the vehicle-end socket, and the status of
charging and the connecon at the vehicle.
Changing the mains-end adapter
⚠ 
· Stop the charging process.
· Before changing out the mains-end adapter, always rst
unplug the mains adapter from the power socket and
the vehicle-end connector from the vehicle.

Prevents adapters and extension
cables from coming unplugged.
Wall bracket
The JUICE BOOSTER 2 can also be
used as a wall-mounted charging sta-
on by ng the specially designed
bracket.
5- and 10-metre extension cables
This enables you to charge your vehicle e. g. at a public
charging staon that’s been blocked by some other vehicle.
Waterproof (IP67) and drive-over resistant. Automac adapter
detecon is likewise transmied. Not specied in a standard,
therefore not CE.
Scope of supply

IC-CPD with the following plugs/connectors:
· Vehicle-end Type-2 connector (or Type-1 coupling)
· Mains-end JUICE CONNECTOR safety connector
· One or more JUICE CONNECTOR mains adapter(s)
· Bag (with Velcro on boom sides, re-resistant)
Parts:
JUICE BOOSTER 2
JUICE CONNECTOR safety connector
Vehicle connector for coupling to the vehicle charging
socket (Type 2 or Type 1)
Mains adapter (also referred to herein simply as
“adapters”, available in numerous version)
Mains connector (in this case CEE32: 400 V, 32 A,
3-phase)
400-V, 32-A, 3-phase heavy-duty cable with control
signal conductors
Bag (with Velcro on boom sides, re-resistant)
 
