GENERAL INFORMATION
ELECTRONIC MODULES
GENERAL INFORMATION
USB Port – This feature is located on the le-side handlebar.
Fig. 9 -
USB Port
Charger - The charger plugs into the electrical outlet. It
energizes the baery pack as needed. The more energy that is
discharged from the baery pack, the longer the charger will
take to recharge.
SPECIFICATIONS
Top Speed 28mph (Class 3 Mode) 30+ mph (Off Road Mode)
Range 100+ miles* (dual-battery setup)
Weight 119 lbs with battery (96 lbs without battery)
Battery Pack 52 VDC Battery/19.2Ah extended range
Charge Time 5-7 hours
Headlight 1,050 lumens
Tires
20 in. x 4.25 in. wide. Inate to psi indicated on
tire
Weight Capacity 275 lbs
* See “Understanding the Baery Pack Range” on page 21
