Juiced Bikes SCORPION X2 - Table of Contents

i
JB2-SCORPX2-MANUAL |
©
2023 JUICED BIKES
California
Proposion 65 Warning
Certain components in this product and its
related accessories contain chemicals
known to the state of California to cause
cancer, birth defects or other reproducve
harm. Wash hands aer handling.
DISCLAIMERS:
All informaon, illustraons and specicaons in this manual are based on the latest informaon available at the me of
publishing. This e-bike is under a connuous improvement policy. Thus, informaon, illustraons and/or specicaons to
explain and/or exemplify a product, service or maintenance improvement may be changed at any me without noce.
IMPORTANT SAFETY INFORMATION:
!
WARNING
!
When using this product, basic precautions should always be followed, including the following:
• Read all the instrucons before using the product.
• To reduce the risk of injury, close supervision is necesary when the product is used near children.
• Do not putngers or hands into the product.
• Do not use this product if the exible power cord or output cable is frayed, has broken insulaon, or any other signs of
damage.
• This equipment is not intended to be used at ambient temperatures less than 5°C (41°F) or above ambient temperatures of
45°C (113°F).
TABLE OF CONTENTS
Introduction ............................ 1
Safety .................................. 2
Before Riding the E-Bike .................................. 3
While Riding the E-Bike ................................... 3
Off-Road Riding .......................................... 3
Wet-Weather Riding ...................................... 4
Night Riding .............................................. 4
Extreme and Aggressive Riding ............................ 4
Electric Bicycle Safety ..................................... 4
10 Safety Topics from the U.S.
Government .............................................. 5
General Information .................... 6
Features .................................................. 6
Electronic Modules ...................................... 11
Choosing the right size ................................... 12
Torque Recommendations ............................... 12
Assembly .............................. 13
Installing the Front wheel ................................ 13
Remove the shipping spacer, bolt and nut from the front
wheel fork. .............................................. 13
Installing the Handlebars ................................. 15
Installing the Pedals ..................................... 15
Adjusting Ride Comfort .................................. 16
Pre Trip Inspection ....................................... 18
Operation ............................. 19
Initial Ride ............................................... 19
Safety Check Before Each Ride ............................... 19
Using the Brakes ......................................... 19
Shifting the Gears ........................................ 19
Pedal Assist Control System .............................. 20
Using the Pedal Assist Control System ........................ 20
Throttle Operation ....................................... 21
Reading the Battery Pack Level ........................... 22
Understanding the Battery Pack Range ................... 22
Factors that Will Decrease Your Range ....................... 22
How to Increase Your Range ................................. 22
Advanced Matrix Display Overview ...................... 23
Button Overview ........................................ 23
Main Display Screen Overview ........................... 24
Battery Voltage (Volts) ....................................... 24
Headlight Graphic ........................................... 24
