Installation
Digging
Package List
Specification Details
NO. Item Qty
A Range Adjustment Board 1
B Exit Wand and Cord 1
2
A
B
Not Included but Necessary
Electrical Gloves, Shovel, Conduit, Spirit Level,
Electrical Tape / Wire Nut, Phillips-Head Screwdriver
Rated Power lnput Voltage
Input Current
Signal Output
12-26V AC/DC
0.036-0.078 W
3 mA
12 ft.
25-125°F
13 ft.
45 ft.
16.5 in.
2 in.
50 ft.
9.8 in.
4.6 lb.
3.6 m
-4 to 69°C
4 m
13.7 m
42 cm
5 cm
15.2 m
25 cm
2.1 kg
Maximum
Length
Minimum
wand
Range Adj. Board
Diameter
Max. Sensing Radius
Recomm. Operating Temperature
Wand to Gate Distance
Wand
Cord Length
Net Weight
Always check for and disconnect any nearby water, electrical, and gas lines
before digging.
Once digging begins, keep any children or passersby away from the area until
everything is covered and finished.
