JUKI LS-1300 Series Handbook

MB-1800B, 1800A/BR10 (September, 2003) 2/4
MB1800
● Machine head, Circuit board
Attachment
For flat button
(small)
For flat button
(medium)
Specification
Without
wiper unit
With
wiper unit
Code
M
Code
S
B
Model Part No. Description
― M8512-630-0A0
Wiper device
(for MB-1800S)
― M8513-630-0A0 2-step pedal unit




PK-51 GPK-510010B0
2-pedal unit
for standing work

PK-57 GPK-570010B0
2-step pedal unit
for standing work
OPTIONS
PATTERN DATA TABLE
DIFFERENCE IN KNOT-TYING METHOD
Feature
A wiper device and thread pulling wire used
in unison to sew buttons without cross-over
stitches.
A foot pedal unit and accompanying pitman
rod. The pedal is operated in two steps, i.e.,
for lowering the button clamp and starting
the sewing machine to facilitate positioning
of the button and sewing product.

＊For PK-51 or PK-57, pedal switch
conversion cable asm.
(Part No.: M9013-590-0A0)
WHEN YOU PLACE ORDERS
Pattern
No.
Shape
Application
Stitch pitch
Stitch
diagram
Number of
stitches
Data setting
range
Data setting
range
1
〜3
4
〜6
7
〜9
10
〜12
13
〜15
16
〜18
19
〜21
22
〜24
25
〜27
28
〜30
31
〜33
34
〜36
37
〜39
40
〜42
43
〜45
46
〜48
49
〜51
4-holed
4-holed
4-holed
4-holed
4-holed
2-holed
2-holed
4-holed
4-holed
3-holed
3-holed
3-holed
3-holed
Label attachment
Button neck wrapping,
2nd process
Zigzag width: 4 mm
Button neck wrapping,
2nd process
Zigzag width: 5 mm
Button neck wrapping,
2nd process
Zigzag width: 6 mm
15, 19, 23, 27
16, 20, 24, 28
15, 19, 23, 27
16, 20, 24, 28
15, 19, 23, 27
8, 10, 12, 14
15, 19, 23, 27
16, 20, 24, 28
17, 23
5, 7
6, 10, 16
2.0〜6.5mm
(in increments
of 0.2 mm)
6.0, 8.0, 10.0mm
2.6, 2.8, 3.0mm
Button neck
height
0
〜6.5mm
(in increments
of 0.2 mm)
＊For all stitch shapes, three different pieces of data can be established by selecting
the number of stitches and stitch pitch within the respective data setting ranges.
MB-1800S, MB-1800B (with wiper unit)
With thread-fray-
prevention function.
MB-1800, MB-377
Conventional
machine
1 2
Should the last stitch undo -
Since the thread knot is securely tied,
the last stitch is unlikely to loosen.
In the event that the last stitch
comes united, the thread will
not easily come off.
State
of the
finished
seam
● Attaching flat button (small)
● Space pin (accessory)
