LK-1903A, LK-1903A/BR35 (September, 2003) 4/4
WHEN YOU PLACE ORDERS
LK1903ASS
LK1903ASS /BR35 S
MC596
● Machine head
● Machine head
● Control box
LK-1903A-SS/Installation of the IP-200B
OPERATION PANEL (You can choose operation panel.)
● Functional settings, such as pattern numbers and needle thread tensions can be
established through the operation panel with ease. Distance between holes in a button
can be easily changed by means of pattern enlargement/reduction feature.
● Standard sewing patterns can be assigned to pattern keys P1 to P50. Any of the sewing
patterns assigned to the P1 to P25 pattern keys can be activated with a touch of the
corresponding key. This means that workability is improved by assigning 25 sewing
patterns that are most frequently used to those pattern keys.
● As many as 20 different cycle sewing patterns, each of which combines a maximum of 30
different sewing patterns, can be stored in the memory.
● The operation panel has been installed at an angle and can be placed at the top, bottom,
right or left part of the table according to the operator's preference.
STANDARD PANEL
IP-200B
＊IP-200B cannot be installed.
Work clamp foot Code
Standard S
Application Code
Standard S
Application Code
Standard S
Work clamp foot Code
Standard S
Button clamp jaw lever Code
For extra-small, small button 301
For medium-size button 302
Button clamp jaw lever Code
For small button 311
For medium-size button 312
Power supply Code
3-phase 200〜240V E
Single-phase
200〜240V K
CE 200〜240V
(not provided with
power switch)
N
Power supply Code
115V C
220V D
Single-phase
240V E
CE 230V
(not provided
with power switch)
G
3-phase 220V K
Operation panel Code
Standard panel SS
IP-200B PB
Operation panel Code
Standard panel S
● A large color LCD touch panel has been adopted for the display.
It gives clear displays that allow the operator to understand operating procedures.
● The IP-200B panel can be connected to a personal computer and can store data on
SmartMedia. This allows data to be exchanged or shared among sewing machines
installed in a factory or among remote factories.
● The IP-200B panel has been provided
with a process improvement supporting
feature through the indication of the
operational state of the sewing machine,
and a maintenance and management
feature for indicating the needle
changing timing and cleaning timing.
Feed plate Code
For small button
(standard: 16mm)
S
For medium-size button
(22mm)
M
To Next Page
