LBH-1790 (September, 2003) 2/4
OPERATION PANEL (You can choose operation panel.)
● The machine is provided as standard with as many as 30 stitch patterns for buttonholing.
qSquare uEyelet square
!3Semilunar
square
!9Square
semilunar
@0Square round
@1
Square straight
bartacking
@2Square taper
bartacking
@3Radial
semilunar
@4Radial round @5Semilunar
radial
@6Semilunar
round
@7Bartacking @8Bartacking,
right cut
@9Bartacking,
left cut
#0Bartacking,
center cut
!4
Semilunar straight
bartacking
!5
Semilunar taper
bartacking
!6Eyelet
semilunar
!7Eyelet round !8Square radial
iEyelet radial o
Eyelet straight
bartacking
!0Eyelet taper
bartacking
!1Semilunar !2Round square
wRound eRadial square rRadial t
Radial straight
bartacking
yRadial taper
bartacking
● All kinds of data can be entered on or selected
from the operation panel.
● Various data, such as pattern numbers and
stitch shapes are indicated on the LCD section
with easy-to-understand pictographs.
● A large color LCD touch panel has been adopted for the display. It gives clear
displays that allow the operator to understand operating procedures.
● The IP-200A panel can be connected to a personal computer and can store data
on SmartMedia. This allows data to be exchanged or shared among sewing
machines installed in a factory or among remote factories.
● The IP-200A panel has been provided with a process improvement supporting
feature through the indication of the operational state of the sewing machine,
and a maintenance and
management feature for indicating
the needle changing timing and
cleaning timing.
STANDARD PANEL IP-200A
Communication screen
SmartMedia card
Connected to a
personal computer
To Next Page
