DP-2100 (August, 2004) 2/2
WHEN YOU PLACE ORDERS
DP2100SZ MC650 PC
● Control box● Machine head
IP-200C
FUNCTION
Smoothing function
Correction pitch setting function
Teaching function
Grading function
Mirroring function
The machine prevents an abrupt change in the shirring
amount at the sewing-step changing point by utilizing a
smoothing function. This upgrades the finished quality of
the seams.
The stitch pitch can be changed on a portion-by-portion
basis. Seam grinning can be prevented by decreasing the
stitch length at a portion where the shirring amount is
large.
Total sewing length is stored in the memory when sewing the portion between notch markes.
This enables the quick and easy programming of sewing data.
When basic data is entered, the data is developed on a size-by-size basis. This helps save the operator from
future program entering work When a program for sewing either sleeve is entered, a program for sewing the
remaining sleeve is automatically created. This helps save the operator from program entering work. It is also
possible to incorporate a change made to either sleeve sewing program into the remaining sleeve program by
means of the mirroring function.
Model
JTDP10
ST2
Description
Table stand (not provided casters)
Auxiliary table
OPTIONS
Application Code
Standard S
Option Code
Not provided Z
Power supply Code
3-phase 200〜240V E
Single-phase
200〜240V K
200〜240V (for CE) N
Operation panel Code
IP-200C PC
The correction
pitch function
is not used.
The correction
pitch function
is used.
Thread is not
adequately tensed.
Shirred portion
Thread is well
tensed.
Sleeve
Needle
entry
Garment body
The smoothing
function is
turned OFF.
The smoothing
function is
turned ON.
Sleeve
Garment body
