AMS-210D, 210D P TYPE (September, 2003) 2/3
SPECIFICATIONS
PROGRAMMING FUNCTIONS
Model name
AMS-210D AMS-210D〈P TYPE〉
AMS-210DS AMS-210DH AMS-210DS AMS-210DH
Application Standard
For heavy-weight
Standard
For heavy-weight
materials materials
Sewing area 60mm (L) ×130mm (W)
Max. sewing speed
2,500rpm (when stitch length is set to 3mm)
2,300rpm (when stitch length is set to 4mm)
Stitch length 0.1〜12.7mm
Needle bar stroke 41.2mm
Lift of the feeding frame Max. 25mm, Pneumatic: Max. 30mm
Lift of the intermediate
Max. 20mm
presser
Stroke of intermediate
Standard 4mm (0.5〜10mm)
presser
Needle DP×5 (#14) DP×17 (#18) DP×5 (#14) DP×17 (#18)
(at the time of delivery) For JE: 134 (Nm100) For JE: 135×17 (Nm110) For JE: 134 (Nm100) For JE: 135×17 (Nm110)
Thread
#80〜#20 #50〜#2 #60〜#30 #50〜#8
B33〜B69 B33〜B207 B33〜B46 B33〜B92
120/3〜40/3 120/3〜10/3 120/3〜60/3 120/3〜30/3
Hook Double-capacity shuttle hook DP double-capacity shuttle hook
Input function Provided as standard
Memory medium 2DD/2HD 3.5" micro-floppy disk
Number of stitches that
Max. 360,000 stitches (max. 20,000 stitches/pattern)
can be stored in memory
Number of patterns that
Max. 691 patterns (2DD)/999 patterns (2HD)
can be input
Enlarging/Reducing facility 1〜400% (by increasing/decreasing the stitch length or the number of stitches)
Error detector function Needle thread breakage detector, temporary stop (pause) switch, error code indicating function
Bobbin thread counter Provided as standard
Sewing machine motor 400W compact AC servomotor (direct-drive system)
Power consumption Single-phase, 3-phase 600VA
Lubrication Automatic
Lubricating oil JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
Total weight 120kg
Dimensions 710mm (L) ×1,200mm (W) ×1,200mm (H)
● With its large memory, the machine responds to many different sewing patterns.
Sewing settings can be established and sewing patterns programmed entirely
through the operation panel.
● Ample storage capacity: maximum of 360,000 stitches on a floppy disk, or 691
patterns on a 2DD disk or 999 ones on a 2HD disk.
● A maximum of 20,000 stitches can be input per pattern. With this large storage
capacity, the machine supports embroidery patterns with large numbers of stitches.
● A sewing pattern can be enlarged/reduced without changing the stitch length.
● Functions that are frequently used during pattern data input (regular stitching
(linear, spline), point stitching, jumping, thread trimming, etc.) are allocated to
specific keys on the operation panel. This reduces the time required for input of
pattern data.
