JUKI LS-1300 Series Handbook

LZ-271, 391N, 586 (September, 2003) 2/2
SPECIFICATIONS
Model name LZ-271
Application Embroidering on light-, medium-, and heavy-weight materials
Max. sewing speed
2,000rpm (with a zigzag width set to 10mm)
1,700rpm (with a zigzag width set to 12mm)
Thread take-up Link type
Needle bar stroke 33.4mm
Needle (at the time of delivery) DB×1 (#11) #9〜#18
Zigzag width 0〜12mm
Zigzag width regulating method Using the jut-type knee lifter with the zigzag width pointer released.
Hook DB-type hook for embroidering
Distance from needle to machine arm 270mm (from the needle entry bottom of the arm)
Lubrication By an oiler
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Model name LZ-391N
Application Embroidering and zigzag stitching light-, medium-,and heavy -weight materials
Max. sewing speed
2,000rpm (with a zigzag width set to 10mm)
1,700rpm (with a zigzag width set to 12mm)
Thread take-up Link type
Needle bar stroke 33.4mm
Max. stitch length 5mm
Stitch length adjustment method Moving the knob up/down
Needle (at the time of delivery) DB×1 (#14) #9〜#16
Zigzag width 0〜12mm
Zigzag width regulating method
Using the knee lifter with the zigzag width pointer released.
If you sew the product with the zigzag width fixed to a certain value, the pointer should be fixed to that value.
Hook DB-type hook for embroidering (capable of using a thick thread)
Distance from needle to machine arm 270mm (from the needle entry bottom of the arm)
Lubrication By an oiler
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Model name LZ-586
Max. sewing speed 3,500rpm
Thread take-up Link type
Needle bar stroke 30.7mm
Max. stitch length 4mm
Stitch length adjustment method Dial system
Lift of the presser foot By hand: 6mm, By knee: 10mm
Reverse feed stitching Lever system
Needle (at the time of delivery) DP×58 or DP×5 (#14) #11〜#18
Zigzag width 0〜6mm
Hook DB-type fully rotating hook
Lubrication Automatic
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Part No. Description Apprication
B3352-271-0A0 Compass (asm.)
B1502-391-BA0 Presser bar joint rod B (asm.) LZ-271, LZ-391N
B5001-271-0A0 Scallop (asm.)
ATTACHMENTS
