DDL-9000 (September, 2003) 2/2
＊To retrofit the AE-8 to your existing machine, I/O unit A (part number: 400-06080), which is separately available, is required.
● SC-910 model control box is resistant to voltage fluctuations.
It comes with a compact and energy-saving type switching
power supply system that does not use a transformer.
This contributes to improved reliability.
● The number of revolutions can be selected from among
three different types (standard, slow and fast) according to
the preference of the operator.
In addition to this feature, the control box incorporates
many different functions for upgraded workability.
OPTIONS
Model Description
AK118
―
AE-8
＊
ED-4
―
Part No.
―
This switch, mounted on the reverse feed switch, enables handy control of various functions.
It is especially effective when operating the machine while standing.
When the amount of remaining bobbin thread reaches the setting, the buzzer will sound to warn
the operator not to press, on the front part of the foot pedal. With this function, the operator
doesn’t have to look away from the sewing work to check the bobbin thread.
(Only supported by the minute-quantity lubricating type machine)
When the sensor detects a material edge, it immediately stops the sewing machine and actuates
the thread trimmer. This enhances productivity by allowing the operator to conduct sewing
work without running to look out for missing stitches.
This device can be installed on the back of the face plate. It is very convenient for frequent use.
Feature
―
236-32656
GAE-080000A0
―
236-11056
Auto-lifter
Optional switch
Remaining bobbin
thread detector
Material edge sensor
Micro-lifter (asm.)
Newly developed control box.
SC-910
● The operation panel has been provided with a large user-
friendly LCD. A pictograph and set values are shown on
the same screen, which promises improved operability of
the panel.
● The operation panel has been provided with a variety of
communication and maintenance control features and is
able to store data on a SmartMedia or personal computer.
● The features of the operation panel can be updated
without the need for changing the PWB/ROM.
The operation panel can be selected according to the process.
IP-100B
● Four different kinds of pattern sewing are possible:
automatic reverse stitching, constant-dimension sewing,
rectangle-shape sewing, and multi-layer stitching.
The maximum number of stitches that can be set for
automatic reverse stitching (single or double) is 19.
CP-160D
