For sewing processes that handle heavy materials or multi-layered parts of material, the
alternating vertical movements of the walking foot and presser foot can be quickly set to
maximum by pressing the DL switch.
The result is beautiful seams free from gathered stitches.
The machine is provided with both a hand switch and
knee switch.
With just a light press on the one-touch type reverse
feed button, reverse feed stitching is actuated.
The machine handles thread counts from #30 to #5.
Its highly rigid thread trimming mechanism cuts the thread
without fail. The machine can be applied to a broad range
of sewing processes, including the sewing of bags.
Since the needle thread-tension-release
solenoid is fitted on the rear face of the
machine head, the area around the needle
entry is easily viewable. This substantially
improves the operability of the machine.
The throat plate and feed dog are provided
with a gauge that offers an excellent
capability for the sewing of sharp curves.
These gauges are especially useful for the
sewing of curves of bags and leather
cases.
V type kit
Pneumatic auto-lifter
Automatic reverse feed devise
Combination of optional devices
Suspended ruler H152
Pedal type lifter
Instantaneous change-over device for the alternate
vertical movement amount (DL device).
＊
V type binder N074
Gauge, Attachment
Model name
Part No.
MAN-0740M0AB
MAN-0740K0AB
MAN-0740H0AB
MAN-0740F0AC
MAN-0740E0AC
Tape width (mm)
26
22
18
13~14
11~12
Finish width (mm)
12
10
8
6
5
Part name
Edge guide
Binder set plate
Part No.
B9101-340-0A0
B9104-340-000
Remarks
−
For binder
Model name
LS-1342-7
Type
AK-147A
AK-147B
AK-147C
AK-147D
AK-147E
Part No.
40103185
40103186
40103187
40103188
40103189
Knee
switch type
○
−
○
−
−
Pedal
switch type
−
○
−
○
○
Switch type
Not
provided
○
○
−
−
○
Provided
−
−
○
○
−
Air regulator
Model name
LS-1340, 1341, 1342
Model name
LS-1342
Part No.
40103191
40103192
Remarks
Accessories set containing [DL-26A + Automatic reverse feed function + AK-147E]
[DL-26B] for installed after the setup of the machine
Model
name
LS-1342
LS-1342-7
Combination
Automatic reverse feed function
Pneumatic auto-lifter
Pneumatic auto-lifter+
Automatic reverse feed function
Pneumatic auto-lifter+
Automatic reverse feed function+
DL device
Pneumatic
auto-lifter
−
AK-147C
AK-147D
AK-147A
AK-147B
AK-147B
AK-147E
Automatic reverse
feed function
○
−
−
○
○
○
Provided as
standard
DL device
−
−
−
−
−
DL-26B
Provided as
standard
Accessories set containing [AK-147E+
Automatic reverse feed function+DL-26A]
3-pedal unit PK70
LS-1342-7-0BB
＊Operation panel CP-180C is optionally available.
The feed mechanism that can synchronize the binder in the piping-tape
attachment process in the sewing
of bags. (The V type kit cannot be
installed on the LS-1342-7.)
＊The DL device cannot be used alone. It must be used in a set together with the automatic
reverse feed function and AK-147E.
＊To mount the DL device to a machine provided with auto lifter and automatic reverse feed
function, the DL-26B should be purchased separately.
＊To use pneumatic auto-lifter and reverse feed function in combination with a machine
that is without automatic thread trimmer, select AK147A or AK147B.
Part No. GPK-700010A0
(for LS-1342-7)
Highly operable
3-pedal unit for
standing work.
Model name
LS-1340
LS-1341
LS-1342
Part No.
214-34758
214-34857
214-34956
LS-1341
Edge guide
The machine is provided as standard with an
instantaneous change-over device for the
alternate vertical movement amount (DL device).
Thread trimming without fail.
Gauge for small articles
are provided as standard.
The area around the needle
entry is designed to be
easily observed.
Cylinder-bed, 1-needle, Unison-feed,
Lockstitch Machine with Large Vertical-
axis Hook and Automatic Thread Trimmer
LS-1342-7
A helpful automatic reverse feed
function is provided as standard.
LS-1340
LS-1341
LS-1342
LS-1340
LS-1341
LS-1342
LS-1340
LS-1341
LS-1342
Part No.
214-33404
SM-6051602TP
214-33503
SM-6051552TP×2
B8133-019-000×2
26037903
Part No.
MAH-152010A0
SS-7151610SP×2
WP-0621016SD×2
WS-0610002KN×2
Pneumatic auto-lifter+
Automatic reverse feed function+
DL device
OPTIONS
