JUKI LS-1300 Series User Manual

− 38 −
Part No.
21332309
SS4110815SP
No.
1
2
Note Name of part
Side cover
Side cover setscrew
Q’ty
1
1
◎ Removing parts list
Part No.
GAKA2302EB0
GAKA20010A0
GAKA20010B0
No.
1
2
3
Note Name of part
AK device (asm.)
AK device (asm.) with knee switch
AK device (asm.)
Q’ty
1
1
1
◎ Installing parts list
Applicable model
LS-1342-7
LS-1340/41
LS1342
Part No.
GAKA14040D0
SK3514000SC
No.
1
2
Note Name of part
Presser foot lifter knee switch B (asm.)
Wood screw
Q’ty
1
2
◎ Kit A (Knee lifter switch)
Part No.
GAKA2302E00
D6043555B0
BT0600401EB
HX00295000A
HX00295000B
No.
1
2
3
4
5
Note Name of part
Solenoid valve E
Pin terminal, male
Air hose
Wire mark [2]
Wire mark [3]
Q’ty
1
2
2
3
3
◎ Pneumatic device components (For LS-1342-7)
