Part No. Part name Q'ty
40072505 Dust-proof rubber (Gray) 1
13155403 Dust-proof rubber (Black) 3
■
Installing the rubber cushion
Install the gray dust-proof rubber to section A only.
[For the V-belt type]
Part No. Part name Q'ty
40072505 Dust-proof rubber (Gray) 2
13155403 Dust-proof rubber (Black) 2
[For the direct-drive type]
