DRAWING OF TABLE (SEMI-SUBMERGED TYPE)
For the V-belt type
4x ø 3.4 on the bottom surface, depth 20
(Drill a hole at the time of set-up.)
4x10.5 hole, depth 26, spot facing depth 3.5
2x ø 3.4 on the bottom surface, depth 10
(Drill a hole at the time of set-up.)
Drilled hole 17
Installing position of drawer stopper (on the reverse side)
Z-Z(4 locations)
Y-Y(3 locations)X-X
