– 2 –
5) Attaching the hinge arm
Install hinge arms
4
to the front and rear (at one location each) of
the sewing machine head with screws
5
. Hook hinge seats
6
on
hinge arms
4
.
(When hooking hinge seats
6
on the hinge arms
4
, face the counter
sunk plane of the hinge seats
6
upward.
6
5
4
6) Installation of the machine
Put the sewing machine head on the table with the sewing machine
head and hinge seats
6
aligned.
Fix hinge seats
6
with wood screws
7
supplied with the unit.
7
2. INSTALLING THE THREAD STAND
Assemble the thread stand, set it up on the machine table using the
installation hole in the table and tighten nut
1
gently.
1
– 3 –
3. LUBRICATION
WARNING :
To avoid possible personal injury due to abrupt start of the machine, turn off the power to the machine and check to be sure that
the motor has totally stopped rotating in prior.
4. INSTALLING THE BELT COVER AND THE BOBBIN WINDER
WARNING :
To avoid possible personal injury due to abrupt start of the machine, turn off the power to the machine and check to be sure that
the motor has totally stopped rotating in prior.
