Jula MarQuant 003-583 - Installation Guide; Wiring Connections

EN
30
13 LOC
Choose whether to control
the car stereo from the front
panel or remote control.
14
ARROW
L/R
Choose between dierent
options.
15 BAND
Switch between frequency
bands.
Answer phone call in
Bluetooth mode.
FIG. 2
INSTALLATION
Connections
NOTE:
Unscrew the lock screws before installation.
To avoid damaging the car stereo connect the
cables according to the wiring diagram.
• The car stereo runs on 12 VDC with negative
earth. Check that the car’s electrical system
matches this before starting the installation.
• The car stereo’s automatic antenna and
subwoofer have separate power supplies.
• The car stereo must be connected according
to the wiring diagram. The car’s electrical
system can be damaged if it is not correctly
connected.
• The speaker cables must be connected to
the correctly marked input.
• Do not block vents or cooling ange,
otherwise the car stereo can overheat and
be damaged.
A1 Video input reversing camera
A2 Subwoofer output
A3 AUX video input
A4 RCA video output
A5 Audio input AUX right
A6 Audio input AUX left
A7 Audio output FR
A8 Audio output FL
B1 Line 1 – steering wheel control
B2 Line 2 – steering wheel control
B3 Control cable for reversing camera
B4 –
B5 Lights control
B6 –
B7 Hand brake control
B8 ACC – ignition control
B9 Radio antenna
B10 B+ power cable
B11 Amplier control
B12 Earth connection
B13 Speaker FR
B14 Speaker FL
B15 Speaker FR+
B16 Speaker FL+
B17 Speaker RR
B18 Speaker BL
B19 Speaker RR+
B20 Speaker BL+
FIG. 3
FIG. 4
Installation
1. Undo the housing from the car stereo with
the keys.
FIG. 5
2. Place the housing in the recess in centre
console in the car.
FIG. 6
