27
Disturbances that are not indicated.
Overload protection:: a) for cooling machine
b) for pump motor
After a short cooling interval, the unit will automatically start running.
Warning:
Before exchanging the fuses, turn off the mains power switch and disconnect
the power plug from the mains socket!
Only use fine fuses with a nominal value as specified.
Fuses:
The mains fuses on the rear of the unit may easily be exchanged as shown on
the left.
Fine fuses –16 A (230 V unit)
Fine fuses –20 A (115 V unit)
Example:
Manufacturer Supplier Type Order No.
Schurter Schurter G-fuse insert SPT T16 A 5x20mm 0001.2516
Schurter Schurter G-fuse insert 172600
TD20,0 A 6,3x32 mm
7043.8230
