OPERATING PROCEDURES
Accessory: Clamp for cooler probe FT200/400 - order no. 8 970 400
5.3. Tube connection FD200
• Connect the tubes and secure with tube clamps.
discharge (9)
intake (10)
Recommended flow rate: 2 to 3 l/min
6. OPERATING PROCEDURES
6.1. Power connection
• Only connect the unit to a power socket with earthing contact (PE –
protective earth)!
• The power supply plug serves as safe disconnecting device from the line
and must be always easily accessible.
• Never operate equipment with damaged mains power cables.
• Regularly check the mains power cables for material defects (e.g. for
cracks).
• We disclaim all liability for damage caused by incorrect line voltages!
Make sure that the line voltage and frequency match the supply
voltage specified on the type plate.
Deviations of ±10 % are permissible.
