Option: Electronic module Order No. 8 900 100
The circulator automatically recognizes the connected electronic module.
10
ALARM
Alarm output (for external alarm signal)
11
STAND-BY
Standby input (for external emergency switch-off)
12
REG+E-PROG
Programmer input and temperature recorder output
13
Connector for supplementary pump or solenoid valve
230 V / max. 1.25 A
No control voltage in the -OFF- condition
14
Connector solenoid valve
1. No control voltage in the -OFF- condition
2. Configurable (Refer to page 65)
15
Fuses (for connectors 13, 14), T1.25A
16
Mains fuses, T16A
17
Mains power cable with plug
20
Cooling coil connectors
21
Pump connectors
suction pump pressure pump
