-8-
ASSEMBLY PROCEDURES
STEP 2
2-1. Remove white cap from the base by pulling on the tab of the cap.
2-3. Replace white cap and ensure it is secure.
STEP 1
Use 2pcs M8X15mm bolts and M8 nuts to connect the bracket with
wheels to the base. Then fasten them.
2-2. FILL WITH FINE GRADE SAND. AFTER FULL WITH SAND - TOP
UP WITH WATER. (This sand can be purchased from
most hardware
stores)
STEP 3
3-1.
Put the 3 pcs support legs on each position on the base as
shown in the picture.
3-2. Use 3 pcs M8 x 16 mm bolts to join the support legs and stand.
STEP 1
Base
Wheel
STEP 3
Bolt
Stand
Square metal
support
legs
STEP 2
To Next Page
