15
3 RTD temperature probe
3.4 Tolerance classes
Change in tolerance depending on the measurement temperature (thin film)
Tolerance classes – temperature validity range (from DIN EN 60751)
t = measurement temperature in °C
± tolerance/K
Measurement temperature/°C
1/3 Class B Class A Class B Class 0.5
Tolerance class Sensor category Temperature range Tolerance
F 0.1 Thin film 0 to 150 °C ± (0.1 K + 0.0017 × |t|)
F 0.15 Thin film -30 to +300 °C ± (0.15 K + 0.002 × |t|)
F 0.3 Thin film -50 to +500 °C ± (0.3 K + 0.005 × |t|)
F 0.6 Thin film -50 to +600 °C ± (0.6 K + 0.01 × |t|)
W 0.1 Wire winding -50 to +250 °C ± (0.1 K + 0.0017 × |t|)
W 0.15 Wire winding -100 to +450 °C ± (0.15 K + 0.002 × |t|)
W 0.3 Wire winding -196 to +660 °C ± (0.3 K + 0.005 × |t|)
W 0.6 Wire winding -196 to +660 °C ± (0.6 K + 0.01 × |t|)
