Transducer short circuit/break
Binary inputs/outputs (option)
Outputs
Interfaces
Short-circuit
1
Break
1
Thermocouple not detected detected
Resistance thermometer detected detected
Resistance transmitter not detected detected
Potentiometer not detected detected
Voltage ≤ ± 210mV not detected detected
Voltage > ± 210mV not detected not detected
Current not detected not detected
1
Programmable reaction of device, e.g. triggering alarm
Input or output configurable as input or output
Number 8, 16 or 24, depending on the device version,
to DIN VDE 0411, Part 500; max. 25Hz, max. 32V
Input
- level logic "0": -3 to +5V (input current max. ±1mA),
logic "1": 12 to 30V (2.5mA ≤ input current ≤ 5mA)
- counting frequency 8Hz
High-speed input the first two binary inputs of each module (B1, B2, B9, B10, B17, B18),
if the module is not fitted with relays or 6 analog inputs
- task count function, e.g. for flow measurement
- counting frequency 10kHz
Output
- type open-collector output, switches relative to positive voltage
- level logic "0": transistor is inhibited
(max. permissible voltage across switching transistor 30V, max. leakage current 0.1 mA)
logic "1": transistor is switched on
(max. voltage across switching transistor 1.6V, max. current 50 mA)
- sampling cycle at least 1sec (1Hz)
1 relay (ex-factory) changeover (SPDT), 3A, 230V AC
1
6 relays (option) changeover (SPDT), 3A, 230V AC
1,2
1
With resistive load.
2
It is not permissible to mix SELV circuits and supply circuits.
RS232/RS485 (connector 7)
- protocol
- baud rate
- modem
- connector
- external inputs
Qty. 1, switchable between RS232 and RS485
Modbus master, Modbus slave and barcode reader
9600, 19200, 38400
can be connected
SUB-D
via the Modbus master/slave function, 24 analog and 24 binary
RS232 for barcode reader (connector 2)
- protocol
- baud rate
- connector
- external inputs
Qty. 1
Modbus master, Modbus slave and barcode reader
9600, 19200, 38400
SUB-D
via the Modbus master/slave function, 24 analog and 24 binary
Ethernet (connector 6)
- quantity
- protocols
- baud rate
- connector
- data format
max. 1
TCP, IP, HTTP, DHCP, SMTP, ModbusTCP
10Mbits/sec, 100Mbits/sec
RJ45
HTML
USB host (connector 5)
- quantity
- use
- max. current
2 (or 1 with stainless steel front),
connector 5 and front connector (not with stainless steel front); no parallel operation
for connecting a memory stick
100mA
USB device (connector 15)
- quantity
- use
2 (or 1 with stainless steel front),
connector 15 and front connector (not with stainless steel front); no parallel operation)
for connecting to the (master) computer
