Jumpking 12ft x 17ft Rectangle Combo User Manual

11
Attach a spring to the diagonal V-ring.
Important: You will now need to use the spring
tool to attach the spring to the frame.
Hook the spring tool onto end of spring, and pull
until the spring can be slotted into the spring slot
on the top of the frame.
IMPORTANT: Ensure the spring is fully
inserted into the slot on the top of the frame.
T-connector+welded tube
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Attach the springs in the sequence shown.
Starting at point 1-4 - Attach 5 Springs to the corner sections.
Continue following the sequence 5-18 keeping the tension even.
Note: The long side of the frame bows outwards until springs pull the fame inwards.
The stitched bed is now fitted and you have completed step 3.
Sleeve
