14
Slot the bottom enclosure pole into the welded tube
attached to the T-Connector. These are visible through
the slots in the frame pad.
Assemble the remaining seven enclosure tubes
using the self tapping screws and the
cross-head screwdriver.
Slot the remaining seven enclosure tubes into the
T -connector+welded tube's on the frame.
The enclosure tubes are now
and you have
completed step 5.
Screw one of the self tapping screws through the slot
in the tubing and into hole using the cross-head
screwdriver.
