MOPS/586 Specifications
Specifications
Mechanical Specifications
PC/104 Bus connector: 2 pieces of 2*32 pin male and 2*20 pin male connector
Module-dimensions: length * width 95 mm * 90 mm (3,7" * 3,5 ")
Electrical Specifications
Supply voltage: 5V DC +/- 5%
Supply voltage ripple: 100 mV peak to peak 0 - 20 MHz
Supply current (maximal): 1,6 A + current DRAM + current Prozessor = 3,5 A
( Σ max. current all Parts)
Prozessor maximal current (AMD-data-sheet): 931 mA
DRAM maximal current (MICRON data sheet): 4 Meg x 32 0,80 A
4 Meg x 32 0,82 A
Supply current (typical, DOS-Prompt):
with 4 MB DRAM 1,29 A
external RTC battery voltage 2,4 – 4,0 V
external RTC battery quiescent current max. 4,5 uA
Environmental Specifications
Temperature: operating 0 to +60 C ((*)with appropriate airflow))
non operating: -10 to +85 °C
Humidity: operating: 10% to 90% (non-condensing)
non operating: 5% to 95% (non-condensing)
(*) The maximum operating temperature is the maximum measurable temperature on any spot on the
modules´s surface. It is the user´s responsibility to maintain this temperature within the above
specification.
