IDE Connector for 2,5" Hard Disk
Pin Signal Pin Signal
1 /RESET 2 GND
3 D7 4 D8
5 D6 6 D9
7 D5 8 D10
9 D4 10 D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND 20 NC
21 NC 22 GND
23 /IOW 24 GND
25 /IOR 26 GND
27 NC 28 BALE
29 NC 30 GND
31 IRQ14 32 /IOCS16
33 SA1 34 NC
35 SA 0 36 SA2
37 /CS0 38 /CS1
39 /HDLED 40 GND
41 VCC 42 VCC
43 GND 44 NC
For signal description please refer additional literatur.
Ethernet Connector
Pin Signalname Function In/Out
1 TXD+ 10BASE-T Transmit differential Output
2 TXD- 10BASE-T Transmit differential Output
3 RXD+ 10BASE-T Receive differential Input
4 NC unused Pin
5 NC unused Pin
6 RXD- 10BASE-T Receive differential Input
7 LNLED LED Output
8 LKLED LED Output
TXD+, TXD-
Differential output pair drives 10 Mb/s Manchester encoded data to the 10BASE-T transmit
lines.
RXD+, RXD-
Differential input pair receives 10 Mb/s Manchester encoded data from the 10BASE-T receive
lines.
LKLED, LNLED
Connect with Cathode of Ethernet-LED‘s.
Feature Connector
Only for manufacture, not for use by customer
