11MHz≤Frequency＜31MHz
31MHz≤Frequency＜61MHz
61MHz≤Frequency≤80MHz
2mVpp~10Vpp
2mVpp~5Vpp
2mVpp~3.6Vpp
Amplitude range of
square/triangle waveforms
Frequency＜1MHz
1MHz≤Frequency＜11MHz
11MHz≤Frequency≤15MHz
2mVpp~25Vpp
2mVpp~20Vpp
2mVpp~10Vpp
Amplitude resolution
1mVpp
Amplitude stability
± 1% ±1 mVpp (@ 1 kHz,>10 mVpp)
Amplitude flatness

±1%(0.1dB)<10MHz

±2%(0.2dB)<10MHz~50MHz

±10%(0.9dB)<50MHz~70MHz
Waveform output
Impedance
50Ω±10% (typical)
Protection
All signal outputs can be on within 60s under load
short circuit
DC Offset
Adjustment range
-9.99V-12.00V
Resolution
0.01 V
Phase characteristics
Adjustment range
0~359.99°
Resolution
0.01°
Measurement and counter function
Measurement mode
Measurement function
Frequency, positive/negative pulse width, period,
duty cycle
Coupling method
DC, AC
Gate time
0.001S-10.000S
Measurement mode
Low frequency, high frequency
Frequency measurement range
1Hz~100MHz
Input signal amplitude range
1Vpp~20Vpp
Period measurement
10nS~4S
Pulse Width
4S
Duty cycle measurement range
0.01%~99.99%
Counter mode
Range
0-4294967295
Coupling method
DC and AC
Counter method
Manual
Modulation characteristics
Modulation type
AM、FM、PM、ASK、FSK、PSK、PWM、BURST
AM
Carrier waveform
Sine, square, ramp, arbitrary (except DC)
Source
Internal/External
Modulation waveform
Sine, square, ramp, noise, arbitrary
