JUNCTEK
JDS8000 Series User’s Manual
【
WAVE
】
key
Press the
【
WAVE
】
key on the front panel to activate the waveforms
switching of the current channel. When the waveform bar is activated,
adjusting the knob can quickly switch waveforms. Press the direction keys
to quickly switch between arbitrary waveforms and preset waveforms. At
the same time, common waveforms such as sine, square, pulse and ramp
are displayed on the right side of the screen. Press the corresponding soft
key to quickly select. When the input box is open, it is the number key 1.
As the
【
WAVE
】
key is in the main interface, it can be used as a waveform
key. In other interfaces, press the
【
WAVE
】
key to return to the main
interface. For example, press the
【
MOD
】
key in the main interface to
enter the modulation interface. Press the
【
WAVE
】
key in the modulation
interface to return to the main interface; however, to enter other interfaces
from the modulation interface and return to the main interface again, you
need to press the
【
WAVE
】
key twice to return to the modulation interface
first and then return to the main interface.
【
MOD
】
Key
For quick switching between modulation mode interface and main
interface.
Press the
【
MOD
】
key to enter the modulation mode. In the modulation
mode interface, press the
【
Type
】
soft key to perform AM, FM, PM, ASK,
FSK, PSK, Pulse, burst and other functions to switch between each other
by rotating the encoder or pressing the direction keys. When the input box
is open, it is the number key 2.
【
SYS
】
Key
For quick switching between the system setting interface and the main
interface.
Press the
【
SYS
】
key to enter the system setting interface, press the
【
PgDn
】
soft key to enter the next page of the system setting interface,
press the
▲ ▼ soft keys to select clear storage, sound, brightness, language,
built-in waveform number , arbitrary waveform number, waveform loading
method, synchronization, frequency fine-adjusting, factory reset and other
items. When the input box is open, it is the number key 3.
【
SWEEP
】
Key
For quick switching between the sweep mode interface and the main
interface.
Press the
【
SWEEP
】
key to enter the sweep frequency interface, press the
【
Func
】
soft key, and then use the corresponding soft key to switch
between the sweep frequency, sweep amplitude and sweep duty functions.
