JDS8000 Series User’s Manual
wave can be realized, which is more accurate than adjusting the duty cycle.
Choose the carrier waveform
The pulse modulated waveform can only be a pulse waveform.
Select pulse
Press
【
MOD
】
→press
【
Type
】
→select pulse by adjusting the knob or
pressing direction keys.
Set waveform reverse
Press
【
W.lnv
】
soft key, you can choose normal or invert to control the output.
Set the pulse width
Press
【
Width
】
soft key to set the pulse width
Use the
【
InBox
】
button to input the required value in the input box (units can
be us, ms, s).
The pulse width ranges from 0.001us to 4s, and the default is 0.100us.
Set the pulse period
Press soft key
【
Period
】
to set the pulse period.
Use the
【
InBox
】
button to input the required value in the input box (units can
be us, ms, s).
The period length ranges from 0.01us to 40s, and the default is 10.00us.
(8) Burst function
The pulse train of 1-1048575 periods can be set to output, and the burst mode
is divided into internal trigger, external input signal trigger (rising edge trigger)
and manual trigger. In use, it should be noted that the cycle time of the burst
pulse train is less than the cycle time of the burst signal.
Select the carrier waveform
Refer to "Selecting Carrier Waveform" in "Amplitude Modulation".
Select Burst
Press
【
MOD
】
→press
【
Type
】
→select burst by adjusting the knob or
pressing direction keys.
Set idle mode
Press
【
Idle
】
soft key, zero position, positive maximum and negative
maximum control output can be selected.
Select trigger source
Press soft key
【
T.Src
】
to select trigger mode.
Key
