Clear memory: used to clear the parameters stored in the current position,
rotate the knob to adjust to the specified position.
Sound setting: Press the
【
On
】
soft key to turn on the sound and press the
【
Off
】
soft key to turn off the sound.
Brightness adjustment: The numeric keys and knob can be used to quickly
adjust the brightness.
Language setting: The knob can be used to select English and Chinese
language.
Built-in waveforms: The numeric keys and knob can be used to set the number
of built-in waves in the instrument, ranging from 00 to 21.
Arbitrary waveforms: The numeric keys and knob can be used to set the
number of arbitrary waves of the instrument, ranging from 01 to 99.
Waveform loading mode:
【
Auto
】
,
【
Fast
】
can be used to select the
waveform loading mode.
System information: Press the
【
...
】
soft key to view the product model,
product serial number, hardware version, firmware version, and FPGA version
of the instrument.
Press soft key
【
PgDn
】
to enter the second page of system settings.
Waveform synchronization: Soft keys
【
ON
】
and
【
OFF
】
can be used to turn
waveform synchronization on and off. (When synchronizing, the CH1 channel
is the operation object, and the parameters of the CH2 channel change with
the change of the parameters of the CH1 channel.)
Frequency synchronization: Soft keys
【
ON
】
and
【
OFF
】
can be used to turn
on and off frequency synchronization.
Amplitude synchronization: The soft keys
【
ON
】
and
【
OFF
】
can be used
to turn on and off the amplitude synchronization.
Offset synchronization: Soft keys
【
ON
】
and
【
OFF
】
can be used to open
and close the offset synchronization.
Duty cycle synchronization: Soft keys
【
ON
】
and
【
OFF
】
can be used to turn
on and off duty cycle synchronization.
