Jungheinrich ECE 225 User Manual

1007.GB
E 2
2 Controls and Displays
Item Control / Display Function
1 Main switch / isolator
(emergency disconnect)
t The circuit is interrupted, all electrical
functions are cut out and the truck
automatically brakes.
2“Horn” button t Triggers a warning signal.
3 “Lower” button t Lowers the lift mechanism.
4 “Lift” button t Raises the lift mechanism.
5 Brake button t The truck brakes at the maximum rate until
it comes to a halt.
6 Controller t Controls the direction of travel and the
travel speed.
7Jet Pilot
Tiller
t
o
Steers the truck.
Steers the truck.
8 Forward “pedestrian / walk-
along operation” button
o Travel starts in pedestrian mode in the
forward direction (V)
(slow travel).
9 Stop button o The electrical functions are deactivated
and the truck automatically brakes.
10 Reverse “pedestrian / walk
along” button
(not for “Touch mode only in
drive direction” option)
o Travel starts in pedestrian mode in the
reverse direction (R)
(slow travel).
t = Standard equipment o = Optional Equipment
1007.GB
E 2
2 Controls and Displays
Item Control / Display Function
1 Main switch / isolator
(emergency disconnect)
t The circuit is interrupted, all electrical
functions are cut out and the truck
automatically brakes.
2“Horn” button t Triggers a warning signal.
3 “Lower” button t Lowers the lift mechanism.
4 “Lift” button t Raises the lift mechanism.
5 Brake button t The truck brakes at the maximum rate until
it comes to a halt.
6 Controller t Controls the direction of travel and the
travel speed.
7Jet Pilot
Tiller
t
o
Steers the truck.
Steers the truck.
8 Forward “pedestrian / walk-
along operation” button
o Travel starts in pedestrian mode in the
forward direction (V)
(slow travel).
9 Stop button o The electrical functions are deactivated
and the truck automatically brakes.
10 Reverse “pedestrian / walk
along” button
(not for “Touch mode only in
drive direction” option)
o Travel starts in pedestrian mode in the
reverse direction (R)
(slow travel).
t = Standard equipment o = Optional Equipment
